Technical specification
Stentering type | Hot air circulating |
Chain type | Pin+clip |
Working type | Horizontal return type |
Working width | 1000-3600mm |
Working speed | 5-60m/min |
Roller width | 2200.2400.2600.2800.3000. |
Overfeeding range | -20-40% |
Stander machine power supply | 380V/3ph /50HZ |
Number of chambers | 4-10 3m long |
Heat source | Thermal oil . Gas .steam |
Edge control system | High precision infra-red type |
Temperature inside of chamber | 100-220 degree |
Technical process flow：
Fabric flatten enter--screw expanding -infra red centering --lower overfeeding -mechanical weft straightening -screw expanding -upper over feeding -Edge uncurling -pinning on or clipping on --Moisture supply -Pin off or clip off -Rubber blanket calendering --Felt compacting treatment -Cool air - plaiting or rolling
